Venetian Blinds between the glass
Blinds-in-Glass is available exclusively within our new or our own existing Windows and Doors
Unfortunately, we do not offer our Blinds-in-Glass in other companies Windows and Doors
Venetian BLINDS
HIGH-PERFORMANCE control of light and shade
Being permanently sealed within the cavity of the double-glazed units makes our Venetian integral blinds unrivaled in the control of light and shade, and the only viable option for light control in bi-folding and sliding doors. The integral blind system which is sealed between glass ensures that you have one of the safest blind systems available.
We offer a huge range of colours to suit any style along with 5 blind control types ranging from manually operated to fully automated solutions. Whether you are seeking a new fit out or wish to retro fit in existing frames we can supply the the perfect integral blinds to suit your requirements.
Designed in Italy, manufactured in the UK and offered with our 5 year guarantee our integral blinds offer the most stylish way to control light and shade in your home
Venetian Colours
The full range available in 28mm Double Glazed Glazed Units
For 24mm Double Glazed Glass Units only White S102, Cream S149 and Silver S157 are available
Please note Blinds in Glass is subject to a compatibility check to ensure suitability for the blind depth and weight
Blinds that stay clean and safe
Our Integral blinds are manufactured to the highest standards and specifications. Once sealed in the dust-free environment of the glazing cavity they will require no cleaning, always appear new and are protected from damage
Blinds in Glass Controller Options
C System Manual Control
SV System Cordless Slide
S System Slider
C System
Manual control Integral blind control system
C System is a patented magnetic system with manual operation (raising and tilting function) for Venetian blinds incorporated within 20mm – 22mm cavity insulating glass units. The external magnet, fixed to the internal glass by double-sided high performance adhesive, allows perfect alignment with the internal magnet. Raising and lowering is controlled using a continuous cord loop that drives the external magnet
The cord is held lightly under tension by a cord tensioner and fully complies with the British Blind and Shutter Association – ‘Make it safe’ campaign. The system is supplied with warm edge spacer bars as standard
C System Benefits
- Suitable for all vertical window applications
- Ideal solution for conservatory shading
- Only viable option for bi-folding doors
- Total privacy and light control for folding sliding doors
- Gives excellent utilisation of partitioned office space
- Suitable for retro installation into existing frames
S & SV System
Cordless slider Integral blind control system
ScreenLine® SL20SV is a manually-operated patented magnetic system with raising and tilting function for Venetian blinds encapsulated within 20mm cavity double glazing units. SL20SV is operated by a magnetic slider, placed on the right or left-hand edge of the glass. A narrow adhesive transparent profile ensures the linear movement of the slider. The blind is raised and lowered by moving the slider up or down and is tilted by slightly lifting or lowering the same slider. SL20SV is suited to all types of window frames. The integrated unit is as straight forward to fit as a standard IGUs. The system is supplied with warm edge spacer bar as standard
Venetian Colour Range and Performance Indicators
Available from our Standard, Exclusive and Extended Colour range. The full range available in 28mm Glazed Units, with White S102, Cream S149 and Silver S157 available in both 24mm and 28mm Glazed Units
Controller Bars are available in White, Grey, Beige, Light Grey and Black
-
S102 White / Solar Reflection 70% / Light Reflection 78% / Solar Absorption 30% -
Metallic Silver / Solar Reflection 65% / Light Reflection 62% / Solar Absorption 35% -
B160 Black / Solar Reflection 4% / Light Reflection 4% / Solar Absorption 96% -
RAL 7016 Anthracite Grey / Solar Reflection 12% / Light Reflection 13% -
DUAL COLOUR S159 Anthracite Grey on S102 White Inside / Solar Reflection 12% / Light Refle -
S158 Slate Grey / Solar Reflection 20% / Light Reflection 21% / Solar Absorption 80% -
S120 Agate Grey / Solar Reflection 41% / Light Reflection 41% / Solar Absorption 59% -
S125 Beige / Solar Reflection 57% / Light Reflection 63% / Solar Absorption 43% -
S106 Yello / Solar Reflection 62% / Light Reflection 72% / Solar Absorption 38% -
S130 Green / Solar Reflection 58% / Light Reflection 65% / Solar Absorption 42% -
S142 Light Blue / Solar Reflection 65% / Light Reflection 69% / Solar Absorption 35% -
S149 Cream / Solar Reflection 68% / Light Reflection 75% / Solar Absorption 32% -
S157 Silver / Solar Reflection 43% / Light Reflection 44% / Solar Absorption 57% -
S157 Silver / Solar Reflection 43% / Light Reflection 44% / Solar Absorption
View or Download the Brochure
SL20SV, SL22SV, SL20SV+ SL22SV+ Venetian
SV
(SV+ has control bar on both sides of Glass Unit)
Possible Dimensions
| Min Width | Max Width | Min Height | Max Height | |
| Glass Unit | 300mm | 1500mm | 450mm | 2200mm |
Feasibility Notes
Maximum Height possible according to width
| Width | Max Height | |
| GU Size | 300mm to 350mm | 1400mm |
| GU Size | 351mm to 400mm | 1800mm |
| GU Size | 401mm to 1500mm | 2200mm |
Maximum area 2m2 with 4mm internal glazing and 1.5m2 with 6mm internal glass
As Approved Installers for Morley Blinds in Glass, we offer our dedicated survey and install service throughout South Wales including Abergavenny, Newport, Cardiff, Barry, Monmouth, Chepstow and Brecon areas and beyond
